OMNITRONIC HDA-4.3

Pojačalo 3 kanala

FEATURES
3-channel amplifier 2 x 350 W + 500 W @ 4 ohms
2 x 200 W + 300 W @ 8 ohms
2 x 350 W + 500 W @ 4 ohms
Low Cut switch on the rear panel
Rotary control for adjusting the upper crossover frequency (Hi Cut) of the subwoofer
3 gain controls
All operation modes controllable via LEDs, can be switched off
Signal inputs via XLR female or terminal block
Speaker connection via terminal block or speaker jacks
Many protection circuits for optimized equipment protection
Forced fan cooling
Very rugged housing
Rack installation

TECHNICAL SPECIFICATIONS
Power supply: 230 V AC, 50 Hz
Output power: Max. 1200 W
Frequency range: 20 - 20000 Hz
Dimensions: Width: 48,3 cm
Depth: 45 cm
Height: 8,9 cm
Weight: 23 kg
Power output sine:
Stereo 4 ohms 2 x 350 W + 500 W
Stereo 8 ohms 2 x 200 W + 300 W
Damping factor: >250
Distortion factor: 0.05 %
Signal-to-Noise ratio: >95 dB
Min. input sensitivity: 0.775 V RMS
Input impedance: 10 kohms (unbalanced), 20 kohms (balanced)
Output impedance: >0.02 ohms
Slew rate: 20 V/µ sec
LED indicators (per channel): Clip, Protect, Signal
Minimum mounting depth: 470 mm
